IP Camera
FTG is a specialized in embedded software, software and hardware research and development, production and sales network devices such as IP CAMERA (Web camera), embedded hard disk video recorders, Server, network storage, switches, routers, wireless network products of technology.
FTG match up with the development of social modernization, we must cut costs in order to achieve the best results, FTG particularly the launch of the network camera "TONE".
"TONE" is the best-selling surplus telecom equipment, network monitoring. The features are characterized by both day or night, regardless of brightness, no matter where you go to, even to travel to other countries, it can observe the real situation of the Internet at any time.
You can also conduct a 24-hour recording, but also at the same time recording, we are more screen real-time notifications of change, when the screen detected any movement, the camera will immediately save the image to the screen and sent to your specify email address or FTP space, whether it is offices, factories, warehouses, shops, shopping malls corridors and to monitor the kids look after by the foreign domestic helpers and so on, FTG "TONE" network camera must be your best choice.
Relevant Instruction:
IPCamera IE Installation Guide
IPCamera Recording Path Setting Guide
View Demo here:
http://ipcam.hkt.cc
Username: demo
Password: demo
Click here for further detail, prices and authorized dealers

Features
> Powerful high-speed video protocol processor
> High sensitivity CMIS sensor
> MJPEG video compression
> Resolution : 640 x 480 (VGA), 320 x 240 (QVGA)
> Video Frame Rate : 30fps (QVGA), 30fps (VGA)
> IR night vision (Range: 10-15m)
> Remote Pan/Tilt rotate (horizontal:270 degree/vertical:90 degree)
> Support two way audio function
> Light Frequency: 50Hz, 60Hz or Outdoor
> Restart immediately when electricity turn down
> Supporting up to 9 users online simultaneously
> Multi-level users management and passwords definition
> Built in web server, supports IE broswer
> Supporting PPPOE, Dynamic IP (DDNS) and UpnP LAN and Internet(ADSL, Cable Modern)
> Giving alarm in cause of motion detection
> Supporting 1 Channel (I/O) alarm function
> Supporting image snapshots
> Supporting multiple network protocols : HTTP/TCP/IP/UDP/STMP/DDNS/SNTPDHCP/FTP)
> Built in RTOS, supports software download and configuration online, that is convenient for camera updating and management
Product Driver and User Manual, PleaseDownload here

| Sensor |
1/4” Color CMOS Sensor |
| Resolution |
640x480 Pixels |
| Lens |
f: 6mm, F 2.0 (IR Lens) |
| Viewing Angle |
60 °C |
| Minimum Illumination |
0.5Lux @ F2.0 |
| Video Compression |
MJPEG |
| Video Frame Rate |
30fps(QVGA), 30fps(VGA) |
| Resolution |
640 x 480(VGA), 320 x 240(QVGA) |
| Flip Mirror Images |
Vertical / Horizontal |
| Light Frequency |
50Hz, 60Hz or Outdoor |
| Video Parameters |
Brightness, contrast |
| Audio talk-back |
Built-in Mic |
| System Interface |
10Base-T/100Base-TX Ethernet Port |
| Supported Protocol |
TCP,UDP,IP,HTTP,FTP,SMTP,DHCP,DNS,ARP,ICMP,POP3, NTP,IPsec,UPNP,RTP,RTCP |
| Pan/Tilt Angle |
Horizontal: 270°C / Vertical: 90°C |
| IR Night |
10-15 meter distance (15ft) |
| Alarm Input |
1 channel on/off input |
| Alarm Output |
1 channel relay output |
| Power Supply |
5VDC/2.0A External Power Adapter |
| Power Consumption |
5W |
| Operate Temperature |
0° ~ 55°C (14°F ~ 122°F) |
| CPU |
2.0GHz or above |
| Memory Size |
256mb or above |
| Display Card |
64m or above memory |
| Supported OS |
Microsoft Windows 98/ME/2000/XP/Vista |
|
|
